Specifications:

1. Flow: 0.8~3.0 liter/mints
2. Suitable capacity of oil reservoir: below 100 liter
3. φ40 Oil Pressure Gauge: 0~10 kg/cm²
4. Weight: 17.7 kgs
5. Dimension: 33×33×44.5 cm
6. Motor: 1/8 HP
7. Voltage: On request
8. Single phase
9. Apply filter core: G-100 x 1 pc
10. Pre-filtering mesh is reusable
11. Length of pipes: 3 meter
12. Length of power cord: 5 meter, 2-conducto
13. Each machine contains one set of filter core

Features:

1. Suitable for low flow machinery.
2. Occupying small space.
3. Operating with single-phase power and built for plug-and-operate use.
4. Equipped with pre-filtering mesh to protect the pump and extend the service life of precision oil filter.
5. Equipped with pump for operating independently, enable to filtration oil continuously, clearness performance reach to NAS grade 6~9, which is even better than new oil, possibly no oil change for 10 years.
6. By using purified oil, the mechanical failure can be substantially reduced, mechanical service life to be extended, also quality and productivity to be improved.
7. Simple installation, no machine stoppage necessary, and easy to maintain.

Order Information:

• Minimum Order: 1
• Branded Product
